SK86E QR Code Cloud Access Control Integrated Machine DC 12V/500mA (Supports 5-30V)

Name: SK86E QR Code Cloud Access Control Integrated Machine DC 12V/500mA (Supports 5-30V)
Brand: Shenzhen Jupin Technology Co., Ltd.
SKU: SK86E
Price: Negotiable USD
Availability: InStock

Brand Name:	Shi Zun
Model Number:	SK86E
MOQ:	Negotiable
Price:	Negotiable
Delivery Time:	10 working days
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Name:

Qr Code Access Control Integrated Machine

Processor:

FreeRTOS Embedded System

Recognition Support:

QR Code, Bluetooth, IC Card, CPU Card, NFC

Protocol Support:

HTTP, MQTT, TCP/IP

External Interfaces:

Dry Contact Output, Exit Button Input, Door Sensor Input, Wiegand, Serial Port (TTL/RS485/RS232)

Supported QR Code Formats:

PDF417 / Data Matrix / QR Code

Reading Angles:

Elevation And Tilt ±65°, Rotation 360°

Scanning Angles:

Horizontal 75°, Vertical 55°, Diagonal 85°

Reading Speed:

<0.2 Seconds

Scanning Distance:

5-15 Cm

Interaction Methods:

Buzzer, OLED Display

Input Voltage:

DC 12V/500mA (Supports 5-30V)

Bluetooth Version:

BLE 4.1

User Storage Capacity:

60,000 Users

Waterproof Rating:

IPX65

Tempered Glass Panel Hardness:

Operating Environment:

Temperature: -20°C To 70°C, Humidity: 5% To 95%

Product Dimensions:

86× 86× 13 (mm)

Product Weight:

150 G

Packaging Details:

86× 86× 13 (mm)

Supply Ability:

100+pcs+day

Highlight:

Desktop access control qr code reader

2d access control qr code reader

Desktop qr code reader access control

Product Description

SK86E QR Code Cloud Access Control Integrated Machine DC 12V/500mA (Supports 5-30V)

SK86E Qr Code Access Control Device Description:

Communication Methods: Ethernet / Wi-Fi / Wiegand / RS485
Access Methods: QR Code / IC Card / CPU Card / ID Card / Mobile NFC / Bluetooth
Communication Protocols: HTTP, MQTT, TCP/IP; Cloud Platform Management, Mini Program Remote Management
Features: Remote Access, Customizable Anti-Copying,
Support for Custom Voice Playback
Supports Secondary Development for Third-Party Platform Integration
Material: Tempered Glass Panel / Metal Casing / Waterproof

SK86E Qr Code Access Control Device Parameters:

Processor	Xtensa 32-bit LX6 Dual-Core Processor, 600 MIPS
Operating System	FreeRTOS Embedded System
Recognition Support	QR Code, Bluetooth, IC Card, CPU Card, NFC
Protocol Support	HTTP, MQTT, TCP/IP
External Interfaces	Dry Contact Output, Exit Button Input, Door Sensor Input, Wiegand, Serial Port (TTL/RS485/RS232)
Supported QR Code Formats	PDF417 / Data Matrix / QR Code
Reading Angles	Elevation and Tilt ±65°, Rotation 360°
Scanning Angles	Horizontal 75°, Vertical 55°, Diagonal 85°
Reading Speed	<0.2 seconds
