Face Recognition Terminal
Created with Pixso. JP189 8-Inch Wall-Mounted Face Recognition Access Control All-in-One Machine HD Camera Industrial-Grade Mainboard

JP189 8-Inch Wall-Mounted Face Recognition Access Control All-in-One Machine HD Camera Industrial-Grade Mainboard

Brand Name: Shi Zun
Model Number: JP189
MOQ: Negotiable
Price: Negotiable
Payment Terms: T/T
Detail Information
Place of Origin:
Guangdong, China
Operating System:
RK 3568, Quad-core CPU, 2.0GHz, Android 11 Version
Configuration:
2GB RAM, 16GB Storage
LCD Screen Size:
8 Inches
Screen Resolution:
800 × 1280
Viewing Angle:
178° Full-view Angle (R/L)
Brightness:
500 Cd/m²
Touch Screen:
10-point Capacitive Touch Screen
Camera:
Dual-lens, 2MP HD, Wide Dynamic Range, Supports Live Detection, With A Shooting Distance Of 0.4-2m
Tri-Color Fill Light:
Green, Red, White
Speaker:
8Ω, 3W
Operating Parameters:
Voltage: 12V Current: 3A Operating Temperature: -20°C To 70°C Humidity: 5% To 90% RH
External Interfaces:
1 × USB/OTG 1 × RJ45 1 × Relay Output 1 × Power Input 1 × Wiegand 1 × RS232/485
Surface Material:
Tempered Glass Front Cover
Body Craftsmanship:
CNC Precision-machined Aluminum Alloy With Anodized Finish
Installation Methods:
Pedestal Turnstile, Wall-mounted, Or Desktop Installation
Color:
Black Front Panel With Silver Edges And Silver Back Cover
Packaging Details:
8 inches
Supply Ability:
100+pcs+day
Highlight:

Column face recognition terminals

,

Android7.1 face recognition terminals

,

Column Face Recognition Temperature Detection

Product Description

JP189 8-Inch Wall-Mounted Face Recognition Access Control All-in-One Machine HD Camera Industrial-Grade Mainboard



Product Overview:
The 8-inch Face Recognition All-in-One Machine is an intelligent terminal device integrated with advanced facial recognition technology, designed for efficient and accurate identity authentication and information management. With its high-speed recognition, robust security, precise accuracy, and rapid response capabilities, it is widely used in various settings, including office buildings, residential communities, schools, and commercial areas.

Technical Features:

  1. HD Camera:
    Equipped with a 2MP wide dynamic dual-camera, supporting multimodal biometric recognition and wide dynamic live detection for accurate and fast facial recognition.
  2. Large Capacity Face Database:
    Supports storage of up to 50,000 face profiles, meeting the needs of large venues.
  3. Industrial-Grade Mainboard:
    Built with a self-developed industrial-grade Android RK3568 chipset for stable 24/7 operation.
  4. Multi-Touch Screen:
    Features an 8-inch LED color screen with 10-point touch support, delivering a smooth interactive experience.
  5. Dustproof and Waterproof Design:
    Industrial-grade dustproof and waterproof protection ensures adaptability to various environments.

Advantages:

  1. High Efficiency:
    Advanced facial recognition algorithms enable fast access, improving work efficiency.
  2. Enhanced Security:
    Biometric technology provides a higher level of security, reducing risks associated with passwords and fingerprints.
  3. Contactless Operation:
    Eliminates the need for physical contact, enhancing convenience and hygiene for users.

Application Scenarios:

  • Smart Office:
    Enables functions such as self-service check-in, attendance tracking, and access control to boost workplace efficiency.
  • Smart Security:
    Quickly identifies suspicious individuals in crowded areas such as airports and stations, enhancing public safety.
  • Unmanned Retail:
    Facilitates payment verification and customer flow analysis in unmanned retail industries, optimizing the shopping experience.

JP189 8-Inch Wall-Mounted Face Recognition Access Control All-in-One Machine HD Camera Industrial-Grade Mainboard 0JP189 8-Inch Wall-Mounted Face Recognition Access Control All-in-One Machine HD Camera Industrial-Grade Mainboard 1JP189 8-Inch Wall-Mounted Face Recognition Access Control All-in-One Machine HD Camera Industrial-Grade Mainboard 2JP189 8-Inch Wall-Mounted Face Recognition Access Control All-in-One Machine HD Camera Industrial-Grade Mainboard 3JP189 8-Inch Wall-Mounted Face Recognition Access Control All-in-One Machine HD Camera Industrial-Grade Mainboard 4
