| Brand Name: | Shi Zun |
| Model Number: | H-A133 Motherboard |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Payment Terms: | T/T |
H-A133 Smart HMI Motherboard quad-core Cortex-A55 architecture processor 2 TTL/RS232 serial ports
H-A133 Smart HMI Motherboard Description:
A133 uses a quad-core Cortex-A55 architecture processor,clock up to 1.6GHZ. It is lower price than quad-core motherboards on the market, maintaining mainstream computing power and 4K high-definition video decoding; compact and ultra-format design, supports LCD RGB screen, suitable for use in digital photo frames, smart commercial display terminals, welcome robots and other scenarios.
H-A133 Smart HMI Motherboard Parameters:
Keyword: | Smart HMI Motherboard | CPU: | Allwinner A133,quad-core Cortex-A53, Clock up to 1.6GHz |
|---|---|---|---|
| GPU: | PowerVR GE8300 | LCD RGB: | 50Pin FPC LCD RGBinterface, supports conventional LCD screens within1024x 768 |
RAM: | Standard 1GB LPDDR4,2GB optional | ROM: | Standard 8GB EMMC, up to 128GB |
USB Host: | 2 external USB2.0, 5 built-in USB2.0 | Serial Port: | 2-way TTL/RS232 serial port,1-way TTL/ RS485 serial ports |
Amplifier Output: | 8 ohm·-6W dual- channel audio amplifier output | Android: | Recommend Android 10.0 |
H-A133 Smart HMI Motherboard Features:
Processor: Equipped with an Allwinner A133 processor, featuring four cores of Cortex-A53, with a maximum clock speed of up to 1.6 GHz, providing a smooth touch interaction experience.
Display Interface: Offers a choice between LVDS or MIPI display interfaces, supporting up to 1080P resolution, compatible with mainstream display screens ranging from 5 to 100 inches.
Video Decoding Capability: Supports 4Kx2K@30fps ultra-high-definition video decoding, suitable for commercial display multimedia playback scenarios.
Wireless Connectivity: Built-in Wi-Fi (default 2.4G single band, configurable for 2.4G/5G dual band) and BT4.2 Bluetooth module.
Memory and Storage: Supports 1GB/2GB/4GB LPDDR4 memory and 16GB/32GB/64GB EMMC storage.
Graphics Processor: Integrated IMG PowerVR GE8300 GPU, supporting OpenGL ES 3.2, Vulkan 1.1, and OpenCL 1.2.
Video Processor: Supports H.265/H.264/VP9 video decoding and H.264/MJPEG/JPEG video encoding.
Ethernet: Provides a 10/100/1000M Ethernet port for fast and stable network connections.
USB Interfaces: Offers 2 high-speed USB HOST and 1 high-speed USB OTG ports.
Expansion Interfaces: Includes support for 4G/5G communication modules, as well as a rich array of serial communication and GPIO interfaces.
System Support: Supports Android 10.0 operating system, as well as other systems such as Ubuntu+Qt, Ubuntu+Xfce, etc.
Size Design: Continues the ultra-thin design of the H series, facilitating users' iterative upgrades.
|
|
| Brand Name: | Shi Zun |
| Model Number: | H-A133 Motherboard |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Packaging Details: | 100mm* 80mm* 9mm |
| Payment Terms: | T/T |
H-A133 Smart HMI Motherboard quad-core Cortex-A55 architecture processor 2 TTL/RS232 serial ports
H-A133 Smart HMI Motherboard Description:
A133 uses a quad-core Cortex-A55 architecture processor,clock up to 1.6GHZ. It is lower price than quad-core motherboards on the market, maintaining mainstream computing power and 4K high-definition video decoding; compact and ultra-format design, supports LCD RGB screen, suitable for use in digital photo frames, smart commercial display terminals, welcome robots and other scenarios.
H-A133 Smart HMI Motherboard Parameters:
Keyword: | Smart HMI Motherboard | CPU: | Allwinner A133,quad-core Cortex-A53, Clock up to 1.6GHz |
|---|---|---|---|
| GPU: | PowerVR GE8300 | LCD RGB: | 50Pin FPC LCD RGBinterface, supports conventional LCD screens within1024x 768 |
RAM: | Standard 1GB LPDDR4,2GB optional | ROM: | Standard 8GB EMMC, up to 128GB |
USB Host: | 2 external USB2.0, 5 built-in USB2.0 | Serial Port: | 2-way TTL/RS232 serial port,1-way TTL/ RS485 serial ports |
Amplifier Output: | 8 ohm·-6W dual- channel audio amplifier output | Android: | Recommend Android 10.0 |
H-A133 Smart HMI Motherboard Features:
Processor: Equipped with an Allwinner A133 processor, featuring four cores of Cortex-A53, with a maximum clock speed of up to 1.6 GHz, providing a smooth touch interaction experience.
Display Interface: Offers a choice between LVDS or MIPI display interfaces, supporting up to 1080P resolution, compatible with mainstream display screens ranging from 5 to 100 inches.
Video Decoding Capability: Supports 4Kx2K@30fps ultra-high-definition video decoding, suitable for commercial display multimedia playback scenarios.
Wireless Connectivity: Built-in Wi-Fi (default 2.4G single band, configurable for 2.4G/5G dual band) and BT4.2 Bluetooth module.
Memory and Storage: Supports 1GB/2GB/4GB LPDDR4 memory and 16GB/32GB/64GB EMMC storage.
Graphics Processor: Integrated IMG PowerVR GE8300 GPU, supporting OpenGL ES 3.2, Vulkan 1.1, and OpenCL 1.2.
Video Processor: Supports H.265/H.264/VP9 video decoding and H.264/MJPEG/JPEG video encoding.
Ethernet: Provides a 10/100/1000M Ethernet port for fast and stable network connections.
USB Interfaces: Offers 2 high-speed USB HOST and 1 high-speed USB OTG ports.
Expansion Interfaces: Includes support for 4G/5G communication modules, as well as a rich array of serial communication and GPIO interfaces.
System Support: Supports Android 10.0 operating system, as well as other systems such as Ubuntu+Qt, Ubuntu+Xfce, etc.
Size Design: Continues the ultra-thin design of the H series, facilitating users' iterative upgrades.
